Aviation Obstruction Light

Name: Aviation Obstruction Light
Brand: SANSAR METAL INDUSTRIES

Get a Price/Quote

MOQ : 10 Pieces Pieces

Aviation Obstruction Light Specification

Life Span
50,000 hours

Beam
360

Efficiency (%)
85%

Housing
UV Stabilized Polycarbonate Cover

Light Color
Red

Shape
Round Dome

Response Time
Instant

Humidity %
10% to 95% RH

Operating Temperature
-20C to 60C

Control Type
Automatic (optional photocell)

Power Supply
Electric

Current Rating
0.05A

Product Type
Aviation Obstruction Light

Material
Polycarbonate, Aluminium Alloy

Base
Surface Mounted

Power Factor
0.85

Input Voltage
110-240V AC

Working Temperature
-20C to 60C

Lamp Power
10W

Application
High rise buildings, Towers, Construction sites, Chimneys

Size
Standard

Dimension (L*W*H)
230 mm x 150 mm x 150 mm

Weight
1.5 kg

Color
Red

LED Type
High Intensity LED

Color Temperature
620-625 nm

IP Rating
IP65

Globe Thickness
3 mm

Ingress Protection
IP65 rated for outdoor use

Visible Range
Up to 2 km

Surge Protection
Integrated

Flash Rate
Steady/Flashing (20-60 flashes/min selectable)

UV Resistance
Yes

Lens Type
Fresnel

Mounting Type
Vertical or Horizontal

Cooling System
Natural Air Cooling

Frequency
50/60 Hz

About Aviation Obstruction Light

Buy or Reserve our Aviation Obstruction Light to champion safety for high-rise buildings and towers. With both vertical and horizontal mounting options, this advanced purchase ensures efficient warning signals, featuring a polished Fresnel lens, robust IP65 ingress protection, and a lofty 2 km visible range. The integrated surge protection, natural air cooling, and UV stabilized polycarbonate housing guarantee reliable, long-lasting performance. This high-intensity LED system comes with automatic control options and a globe thickness of 3 mm, making it the ideal choice for outdoor applications in India. Secure your site with this expertly engineered solution today.

Usage & Special Features

This Aviation Obstruction Light is designed for steady or selectable flashing, ideal for installation on towers, chimneys, and construction sites. The application method supports both vertical and horizontal mounting, while the 360-degree dome shape maximizes visible coverage. Enhanced features include integrated surge protection, UV-resistant UV-stabilized polycarbonate housing, and automatic photocell control for seamless operation. The surface-mounted base, instant response time, and wide input voltage range underscore its high utility in safeguarding aviation routes.

Export Logistics & Packaging Details

Our Aviation Obstruction Light is available for international handover through trusted FOB ports across India. Main export markets include Asia and the Middle East, with express shipping options arranged to ensure timely delivery. Carefully packaged for optimal protection, each unit is secured in durable boxes tailored for global logistics handling. Buyers enjoy streamlined purchase processes and responsive after-sales support, making the product delivery and logistics experience efficient and worry-free.

FAQ's of Aviation Obstruction Light:

Q: How do I install the Aviation Obstruction Light for optimal visibility?

A: The light can be installed either vertically or horizontally, depending on the mounting surface and required coverage. Its surface-mounted base and 360-degree beam ensure excellent visibility regardless of orientation.

Q: What are the key benefits of the integrated surge protection in this light?

A: The surge protection prevents electrical spikes from damaging internal components, ensuring consistent operation and an extended lifespan even in challenging outdoor environments.

Q: When should the automatic photocell control be used?

A: Automatic photocell control is ideal when you require the light to activate at dusk and switch off at dawn, offering hands-free operation and energy savings.

Q: Where can this Aviation Obstruction Light be applied most effectively?

A: It is particularly suitable for high-rise buildings, telecom towers, chimneys, and construction sites where clear aviation warning signals are mandatory.

Q: What is the process for advance purchase or reserving units in bulk?

A: To advance purchase or reserve, contact the supplier or manufacturer directly through their provided channels. Specify your quantity and any customization requirements to streamline order processing.

Q: How does the UV-stabilized polycarbonate cover improve product performance?

A: This feature shields the housing from harmful sun exposure, preventing discoloration and maintaining clarity, which enhances long-term durability and operational reliability outdoors.
